Type B - Polypropylene Cam and Groove Coupling
In stock
SKU
Type-B-coupler-Polypropylene
Size | 1/2" to 4" |
---|---|
Part Number | Type B |
Material | Polypropylene |
Handles | Stainless Steel 304 |
Gasket | EPDM |
Thread | Male NPT |
CLICK HERE for All Poly Couplers and Adapters
- ● The Type B coupler is ordinarily used with a matching size Type F adapter
- ● However, this Type B coupler can be used with a identical size Type A or Type E adapters.
- ● They can be sealed closed with a Type DP (Dust Plug) of matching size.
- Description:
- ● Polypropylene Female Cam and Groove Adapter x Male NPT Thread
- How To Use:
- ● To connect, slide the Type B Coupler onto a Male Adapter and then close the two cam handles at the same time.
- ● To disconnect, lift up the cam lever arms and uncouple the two pipe fittings.
- To Install:
- ● Thread the Male NPT portion into a Female NPT Thread.
- Will connect with:
- ● The coupler portion will couple with a Male Adapter.
- ● The threaded end will connect to a Female NPT Thread. (National Pipe Thread)
- Used for:
- ● Installing a Female Cam & Groove into a Male NPT Threaded end.
- ● Connecting with a Male Adapter of matching size.
- Sizes:
- ● This Poly Coupler is offered in sizes starting from 1/2" up to 4".
- Material of Construction:
- ● Constructed out of Polypropylene.
- ● For other materials scroll Down to "Related Products".
Dimensions:
Size(mm) | 1/2 | 3/4*1/2 | 3/4 | 1 | 1-1/4 | 1-1/2 | 2 | 2-1/2 | 3 | 4 |
A | 34.6 | 41.5 | 41.5 | 49 | 58.4 | 67 | 82 | 94.5 | 110 | 144 |
B | 25.1 | 32.5 | 32.5 | 37.3 | 46 | 54 | 64 | 76.5 | 92.3 | 120 |
L1 | 53 | 54.7 | 54.7 | 61 | 65.5 | 73 | 84 | 85.5 | 90 | 95 |
Type B Female Couplers can be used with Type A, Type E , or Type F adapters as well as with Type DP (Dust Plugs).
Specifications:
Size | 1/2" to 4" |
---|---|
Part Number | Type B |
Material | Polypropylene |
Handles | Stainless Steel 304 |
Gasket | EPDM |
Thread | Male NPT |
